FG500 Heavy-Duty Flywheel Grinder Machine | Professional Engine & Clutch Repair Equipment

Featured

Brand: HOWANN

Part Number: FG500

Category: Engine Repair Equipment

Availability: In Stock

Interested in this product?

Send us an inquiry for pricing and availability.

Specifications

Quick Specs:

*Application:Passenger Car & Heavy-Duty Commercial Flywheels
*Max. Flywheel Diameter:500 mm (Suitable for large clutches)
*Grinding Wheel Speed:High-efficiency precision spindle speed

Full Specifications:

Model	FG500
Function	Automotive & Commercial Flywheel Grinding / Resurfacing
Max. Grinding Diameter	500 mm
Max. Workpiece Height	250 mm
Grinding Wheel Diameter	150 mm
Table Rotation Speed	15 / 30 rpm
Spindle Motor Power	2.2KW
Power Supply	380V / 220V (50/60Hz, 3-Phase)/customized

Product Description

The FG500 Flywheel Grinder is a premium-grade, heavy-duty resurfacing machine engineered specifically for automotive machine shops and engine rebuilders. Designed to handle passenger cars, light trucks, and heavy-duty commercial flywheels, it delivers an ultra-flat, mirror-like finish. With its rigid column structure and precise rotary table, the FG500 eliminates clutch chatter and restores smooth clutch engagement with unmatched efficiency.

Key Features & Benefits

*High-Precision Grinding:Specially designed for flat and stepped flywheels, ensuring perfect parallelism and surface finish.
*Heavy-Duty Cast Iron Base:Provides maximum rigidity and absorbs vibrations to guarantee micro-inch accuracy during operation.
*Efficient Rotary Table:Smooth and powerful rotation allows for fast setups and consistent grinding depth across the entire surface.
*Versatile Adaptation:Easily accommodates a wide variety of domestic and import flywheels, including heavy commercial vehicle clutches.
*Built-in Coolant System:Integrated cooling system prevents thermal warping of the flywheel during high-load grinding, extending grinding wheel life.

*Comes with a comprehensive adapter and cone kit for rapid flywheel mounting
